• Different types of driver circuits are available, such as unipolar and bipolar driver circuits. Unipolar driver circuits are suitable for unipolar stepper motors, while bipolar driver circuits are used for bipolar stepper motors. For example, the L293D is a commonly used driver chip for unipolar stepper motors, and the A4988 is popular for bipolar stepper motors.
3. Control Signals:
• The control of a stepper motor is achieved through a series of digital pulses. The number of pulses determines the number of steps the motor will take, and thus the angle of rotation. For example, if a stepper motor has a step angle of 1.8 degrees, and 200 pulses are sent to it, the motor will rotate through 360 degrees (since 200 x 1.8 = 360).
• The frequency of the pulses controls the speed of the motor. A higher frequency of pulses will result in a faster rotation speed, while a lower frequency will make the motor rotate more slowly.
4. Programming for Control:
• When using a microcontroller to control a stepper motor, programming is required. For instance, if using an Arduino, code needs to be written to send the appropriate digital pulses to the driver circuit at the desired frequency and in the correct sequence. The code will typically define the number of steps, the speed (by setting the pulse frequency), and the direction of rotation (by changing the order of the pulses for forward or backward rotation).
III. Characteristics of Stepper Motors
1. Precision Positioning:
• Stepper motors offer high precision in positioning. The step angle of a stepper motor determines how precisely it can be controlled. For example, a stepper motor with a step angle of 0.9 degrees can achieve a much finer positioning compared to one with a step angle of 1.8 degrees. This makes them ideal for applications like CNC machines where accurate cutting or drilling positions are crucial.
2. Open-Loop Control:
• One of the significant advantages of stepper motors is that they can be controlled in an open-loop manner. This means that once the motor is set to rotate a certain number of steps, it will do so without the need for continuous feedback about its actual position. This simplifies the control system as there is no requirement for additional position sensors in many cases. However, it should be noted that in some high-precision applications or when there are external disturbances, closed-loop control with additional position sensors might be necessary.
3. Low Speed Torque:
• Stepper motors typically have good torque characteristics at low speeds. They can provide a relatively high torque even when rotating slowly. This is useful in applications where a slow and steady movement with sufficient force is required, such as in some robotic arm applications where the arm needs to move objects carefully at a slow pace.
4. Digital Control Compatibility:
• Stepper motors are very compatible with digital control systems. Since they are controlled by digital pulses, they can be easily integrated with microcontrollers, digital signal processors (DSPs), and other digital control devices. This allows for precise and flexible control of the motor's operation, such as changing the speed, direction, and number of steps on the fly.
5. Discrete Movement:
• The movement of a stepper motor is discrete, meaning it moves in distinct steps rather than continuously like a DC motor. Each step corresponds to a specific angle of rotation. This discrete movement property makes it easier to calculate and control the exact position of the motor, which is beneficial for applications that require accurate positioning and repeatability.
In conclusion, stepper motors are versatile devices with unique characteristics that make them suitable for a wide range of applications where precision positioning, digital control, and discrete movement are desired. Their proper use requires understanding of power supply, driver circuits, and control signal generation, along with an awareness of their inherent characteristics.

3. Feedback and Control: Advanced motors in intelligent surgical equipment are often equipped with sensors that provide feedback on their performance. For instance, encoders can measure the rotation angle and speed of the motor, sending this information back to the control system. Based on this feedback, the control system can make adjustments to ensure that the motor operates within the desired parameters. This closed-loop control mechanism helps to maintain the accuracy and stability of the surgical equipment's movements, preventing any unexpected deviations that could affect the surgical outcome.
Precision Parts in Intelligent Surgical Equipment
1. Enhanced Mechanical Precision: Precision parts, such as bearings, gears, and shafts, are essential for ensuring the mechanical precision of the surgical equipment. Bearings are used to reduce friction and support the smooth rotation of moving parts. In a surgical microscope, for example, high-quality bearings ensure that the focusing mechanism can be adjusted with great precision, allowing surgeons to clearly observe the surgical site. Gears are used to transmit power and change the speed or torque of the movement. They are carefully machined to ensure accurate meshing and smooth operation, which is crucial for the proper functioning of the equipment. Shafts are responsible for connecting different components and transmitting mechanical forces. Their dimensional accuracy and surface finish directly affect the performance of the equipment.
2. Miniaturization and Compactness: Many intelligent surgical equipment designs require precision parts to be miniaturized and made more compact. This is especially true for handheld surgical devices or those that need to be inserted into the body, such as endoscopic tools. Miniaturized precision parts, such as micro-gears and micro-bearings, allow the equipment to be smaller in size while still maintaining high functionality. For example, in a minimally invasive surgical endoscope, miniaturized precision parts enable the device to have a slender profile that can be easily inserted through small incisions, while still providing the necessary mechanical support and functionality for the surgical operation.
3. High-Quality Materials and Durability: Precision parts used in intelligent surgical equipment are typically made from high-quality materials to ensure durability and reliability. Stainless steel, titanium alloys, and ceramics are commonly used materials. Stainless steel is known for its corrosion resistance and mechanical strength, making it suitable for many structural components. Titanium alloys offer excellent biocompatibility and strength-to-weight ratio, which is important for parts that come into contact with the body. Ceramics, such as alumina or zirconia, are used for their high hardness and wear resistance, especially for components like cutting tool tips. These high-quality materials ensure that the precision parts can withstand the rigors of surgical operations and maintain their performance over time.
In conclusion, the application of motors and precision parts in intelligent surgical equipment is a key aspect of modern surgical technology. Their combination provides the necessary mechanical movement, precision control, and durability required for performing complex and precise surgical procedures with enhanced safety and effectiveness.

3. Facilitating Automatic Operation
Motors also contribute to the automation of lathe operations. In automated or semi-automated lathes, motors are integrated with programmable logic controllers (PLCs) or CNC systems to execute a series of machining tasks automatically. They can control not only the rotation of the spindle but also the movement of the cutting tool along the workpiece. For example, motors can drive the tool carriage to move in the axial and radial directions precisely according to the programmed cutting paths. This automation reduces the reliance on manual operation, improves production efficiency, and ensures consistent quality in the manufactured parts. It also enables mass production of identical components with high precision, which is crucial in industries such as automotive and aerospace where large numbers of precision parts are required.
4. Improving Machining Precision
The use of motors in lathes helps to enhance machining precision. As mentioned before, the precise speed control and accurate positioning capabilities of motors contribute to this. Additionally, motors with high torque and smooth operation characteristics can ensure that the spindle rotates stably during the cutting process. This stability minimizes vibrations that could otherwise affect the dimensional accuracy and surface finish of the workpiece. In high-precision lathes, motors are carefully selected and calibrated to meet the strict tolerance requirements of the final products. For example, in the production of miniature mechanical parts or components for high-tech devices, the precise operation of motors in the lathe is vital to achieving the extremely fine tolerances needed for these parts.
In conclusion, motors are indispensable in the application of lathes, providing power, enabling precise control, facilitating automation, and improving machining precision, all of which are essential for efficient and high-quality lathe machining operations.
